SETTINGS AND MAIN SCREEN

While powering up, the model name and software version will be displayed on the LCD for 2 seconds, following which the charger

enters the main screen. The main screen displays the settings of the memory prole you used the previous time. You can modify the

main settings in the same screen.

On the main screen, you can select from your saved

memory proles, adjust battery type and charge/

discharge/cycle/storage function. After you choose

each parameter, the display will automatically

update corresponding to your selection.

Memory proles

The charger has 10 memory slots. Each memory slot can store the settings of dierent types of batteries. The most popular battery

charging settings have been pre-programmed and stored in the memory slots. From the main screen, press the “Enter” button until

the memory selection eld ashes. Using the “–“ and “+” button, select the desired memory slot from M01 to M10. The battery

settings and charge/discharge function programmed for that slot will automatically be displayed in that memory slot.

By pressing “Enter” the display will scroll through the parameters that you can change.

Pilotage Simplex 4(6)

Competition V1 . 6

Battery Capacity

Memory Series

Battery Type

Charge/Discharge/Cycle/Storage Function

Balancer

Battery Parameters

M01 LP CHG 4 . 20V 4S

5000mAH 5 . 0A BLC - OFF

Charge Current
