SYNCHRONIZATION
115
If the LOCK and TACH lights do not behave as described,
your Express interface is not successfully locking to the
SMPTE time code. This could be a problem with the audio
connections between the tape deck and your Express
interface. It could also be that the SMPTE level is not high
enough. See Appendix C, “Troubleshooting and Customer
Support” page (147).
If the LOCK and TACH lights look OK, but the green
computer OUT LED is not glowing, this means that your
Express interface settings have been altered somehow such
that it is not sending MIDI time code to the computer. To
correct the settings, see Figure 8-1.
Time code display
ClockWorks displays a running update of time code when
the Express interface is converting time code.
Routing MIDI Time Code to other devices
At times, you may need to route MIDI Time Code to a
device connected to one of your Express interface’s MIDI
OUTs. To make time code routings such as these, see “The
MTC In and MTC Out connections” on page 34 (or
page 70 for Mac OS 9 users).
Freewheeling to avoid time code dropouts
When your Express interface encounters a drop-out —a
series of missing or unreadable frames—in the SMPTE
time code, it “freewheels” past them, pretending that they
were not missing by briefly generating its own code to
make up for the missing frames. The default freewheel
value is 4 frames. This means that your Express interface
will continue to generate time code for four more frames
after it stops receiving time code. If it does not receive any
more time code after four frames, it will stop converting.
The factory default base setups have the freewheeling
feature set to 4 frames for fastest response when you stop
the tape deck. The Freewheel amount can be adjusted up
to 32 frames. This allows your Express interface to
maintain lockup even over lengthy SMPTE drop outs.
If you encounter a time code drop out that causes your
Express interface to stop converting for a moment, try
increasing the freewheel amount in ClockWorks. Try
adding just a few frames at a time when adjusting the
amount.
