CLOCKWORKS FOR MAC OS X

Selecting a connection

To select a connection, click the connection’s input cable

icon on the left or one of its output cable icons on the right.

Deselecting all connections

To deselect all connections, click anywhere in the middle

of the window between the two columns of cables.

Breaking a connection

To break a connection, select the connection by clicking its

cable icon, and press the delete key.

Breaking one of several connections

Often, a device will be connected to several other devices.

To delete just one of the connections:

1 Redraw the connection you want to break.

2 Press the delete key to remove the highlighted

connection.

The MTC In and MTC Out connections

The MTC In and MTC Out connectors represent MIDI

Time Code (MTC) routing to and from the interface itself.

If you would like to send MIDI Time Code from your

MOTU interface to devices connected to its MIDI Out

ports, create a connection from the MTC Out port (on the

left) to the desired device(s) on the right.

Routing MTC to your MOTU interface

If you would like to slave your MOTU interface to MIDI

Time Code generated by another device, make a

connection from the device (on the left) to the MTC In

port (on the right).

Routing MTC to the computer port

From the factory, your MOTU interface is programmed to

send MTC to the computer port, as shown in Figure 5-2 on

page 33. This connection is required by any MIDI software

that needs to slave to MTC generated by the interface.

The MMC Out and MMC In ports

The MMC Out and MMC In ports provide routing of

MIDI Machine Control (MMC) transport commands to

and from your MOTU interface itself. For example, if you
