CLOCKWORKS FOR MAC OS 9

from your MOTU interface via MIDI Time Code. It also

provides valuable status information about your MOTU

interface itself.

The SMPTE Reader window

The SMPTE Reader provides a running update of the time

code being generated or converted by your MOTU

interface. This running update is made possible by MIDI

Time Code (MTC) generated by your MOTU interface

and routed to the Macintosh. If the SMPTE Reader is not

responding, make sure in the Device Settings & Routing

window that the MTC Out port on the left is connected to

the computer port on the right.

The SMPTE Reader shows your MOTU interface’s current

frame location in hours: minutes: seconds/ frames.

Figure 6-37: The SMPTE Reader provides a running update of your MOTU inter-

face while it is generating or converting time code.

If you click the triangle in the lower left-hand corner of the

window, an additional status display appears at the bottom

of the window. This area shows what state your MOTU

interface is in at any given time.

Figure 6-38: The triangle along the left-hand side of the window opens and

closes the status display at the bottom of the window.

SMPTE Reader status display

The SMPTE reader status display can be opened by

clicking the triangle in the lower left-hand corner of the

SMPTE Reader, as shown in Figure 6-38.

The status area provides detailed information about what

state your MOTU interface is in as a synchronizer. The

following sections provide a brief explanation of each

term.

Opens the separate status window shown in

Figure 6-39 on page 88.
