SOLID STATE LOGIC Alpha Link MX 16-4 IO Bundle [21/52] Specifications
![SOLID STATE LOGIC Alpha Link MX 16-4 IO Bundle [21/52] Specifications](/views2/2007975/page21/bg15.png)
15
EN
DE
ES
FR
IT
JP
Specifications
Physical *
Depth 220mm / 8.75"
casing only
Height 45mm / 1.75" (1 RU)
Width 435mm / 17"
casing only
482mm / 19"
inc’ rack ears
Weight 2.8kg / 6.25 pounds
Power < 25 Watts
Boxed size 635mm x 320mm x 150mm
25" x 12.75" x 6"
Boxed weight 4.5kg / 10 pounds
* All values are approximate
Environmental
Temperature Operating: +5 to 30 deg. C
Non-operating: –20 to 50 deg. C
Max. gradient: 15 deg. C/hour
Relative Operating: 20 to 80%
Humidity Non-operating: 5 to 90%
Max. wet bulb: 29 deg. C
(non-condensing)
Vibration Operating: < 0.2 G (3 – 100Hz)
Non-operating: < 0.4 G (3 – 100Hz)
Shock Operating: < 2 G (10ms max.)
Non-operating: < 10 G (10ms max.)
Altitude Operating: 0 to 3000m
(above sea level) Non-operating: 0 to 12000m
Connections
Power IEC320 3-pin connector, 100 – 240 Vac, 50 – 60 Hz
Analogue I/O 25-pin D-type socket, Zin > 10kΩ, Zo ≈ 100Ω
MADI I/O 1 x twin SC type chassis socket,
glass multimode fibre 50/125µ (65/125µ compatible)
USB 1 x type-B chassis socket
(for firmware upgrades)
Sync 75Ω BNC, Zin/out ≈ 75Ω, 3V3/5V TTL compatible
Performance
Quantisation 24bit, fixed point
Analogue I/O Level Balanced, +14dBu to +24dBu maximum
(selectable from front panel)
Electro Magnetic Compatibility
EN55103-1:2009, EN55103-2:2009
Environments E1, E2, E3 and E4
Initial in-rush current 36A
5 sec in-rush current 36A
Braid-screened cables should be used where applicable
Star Quad cables should be used where applicable
EMC Performance Criteria
Line level inputs and outputs
Measure at mid-gain, noise <–56dBu
