Déballer
L’emballage de votre Alpha-Link MX doit contenir:
XLogic Alpha-Link MX
Installation and User Guide
Hinweise zur Installation
Guía de Instalación
Guide d’Installation
Installazione Prodotto
インストール・ガイド
XLogic Alpha-Link. This is SSL.
EN
DE
ES
FR
IT
JP
5A
Guide d’Installation
(ce document)
JP
(marqué ‘PSE’)
ouou
Plusieurs cordons secteur peuvent être
fournis avec l’appareil, veuillez SVP ranger
dans un endroit sécurisé les cordons que
vous n’utilisez pas.
ou
US
(marqué ‘UL’)
EU
4 Cordons Secteurs
L’unité XLogic Alpha-Link MX
(L’Alpha-Link MX 16-4)
