SOLID STATE LOGIC Alpha Link MX 16-4 IO Bundle [33/52] Datos técnicos
![SOLID STATE LOGIC Alpha Link MX 16-4 IO Bundle [33/52] Datos técnicos](/views2/2007975/page33/bg21.png)
27
EN
DE
ES
FR
IT
JP
Datos técnicos
Medidas *
Profundidad 220mm / 8,75"
solo la caja
Alto 45mm / 1,75" (1UA)
Ancho 435mm / 17"
solo la caja
482mm / 19"
incluyendo asas de rack
Peso 2,8kg/ 6,25 libras
Potencia elec. < 25 Watt
Tamaño embalaje 635mm x 320mm x 150mm
25" x 12,75" x 6"
Peso embalaje 4,5kg / 10 libras
* valores aproximados
Medio Ambiente
Temperatura Funcionando: +5 a 30 grados C
Conectado: –20 a 50 grados C
Variación. max.: 15 grados C/hora
Humedad rel. Funcionando: 20 à 80%
Conectado: 5 à 90%
Max. wet bulb: 29 grados C
(non-condensados)
Vibración Funcionando: < 0,2 G (3 – 100 Hz)
Apagado: < 0,4 G (3 – 100 Hz)
Choque Funcionando: < 2 G (10ms max.)
Conectado: < 10 G (10ms max.)
Altura (sobre Funcionando: 0 – 3000mts
nivel del mar) Conectado: 0 – 12000mts
Conexiones
Alimentación Conector IEC320 de 3 pines, 100 – 240 Vac, 50 – 60 Hz
I/O analógicos Toma tipo D de 25-pins, Zi > 10kΩ, Zo ≈ 100Ω
MADI I/O 1 x toma de corriente chasis de tipo Twin SC,
fibra de vidrio multimodo 50/125µ (65/125µ compatible)
USB 1 x toma chasis tipo B
(para la actualización del firmware)
Sync 75Ω BNC, Zin ≈ 75Ω, 3V3/5V TTL compatible
Rendimiento
Cuantización 24bit, punto fijo
Nivel I/O analógico Balanceada, +14dBu a +24dBu máximo
(seleccionar desde el panel frontal)
