37
EN
DE
ES
FR
IT
JP
Connessione
Per le piedinature dei connettori consultare pagina 3.
Switch dell’unità ID (collegamento loop-through)
Posizione Funzione
I unità nella catena MADI
(predefinita)
II unità nella catena MADI
III unità nella catena MADI
IV unità nella catena MADI
16 Ingressi analogici
4 Uscite
analogici
16 Uscite analogici
4 Ingressi
analogici
Alpha-Link
MX 16-4
Alpha-Link
MX 4-16
USB
(solo per aggiornamento del Firmware)
Ingresso/Uscita MADI
Ingresso Wordclock,
uscita Wordclock
Ingresso rete di alimentazione AC
