17
EN
DE
ES
FR
IT
JP
Auspacken
Folgendes sollten Sie in der Verpackung finden:
XLogic Alpha-Link MX
Installation and User Guide
Hinweise zur Installation
Guía de Instalación
Guide d’Installation
Installazione Prodotto
インストール・ガイド
XLogic Alpha-Link. This is SSL.
EN
DE
ES
FR
IT
JP
5A
Hinweise zur Installation
(dieses Handbuch)
JP
(bez. als PSE)
oderoder
Eventuell werden mehrere Netzkabel mitgeliefert.
Bitte entsorgen Sie unbenutzte Kabel ordnungsgemäß.
oder
US
(bez. als UL)
EU
4 Netzkabel
Das XLogic Alpha-Link MX Gerät
(Die Abbildung zeigt einen Alpha-Link MX16-4 )
