31
EN
DE
ES
FR
IT
JP
Connectique
Veuillez vous référer à la page 3 pour le brochage des connecteurs.
Commutateur Unit ID (boucle MADI)
Positions Fonction
Unité 1 dans la chaîne MADI
(défaut)
Unité 2 dans la chaîne MADI
Unité 3 dans la chaîne MADI
Unité 4 dans la chaîne MADI
16 Entrées Analogiques
4 Sorties
Analogiques
16 Sorties Analogiques
4 Entrées
Analogiques
Alpha-Link
MX 16-4
Alpha-Link
MX 4-16
USB
(uniquement pour mise à jour du firmware)
Entrée/Sortie MADI
Entrée Wordclock,
Sortie Wordclock
Alimentation Secteur
