BM series 41
Display refresh rate ( 5pd )
The periodic time to refresh the display. This parameter influences "Baud rate", "Data output
pause" and the data output rate of "Stream mode".
Decimal point ( pnt )
The decimal point format can be selected.
Auto display-ON ( p-on )
When the AC adapter is plugged in, the display is automatically turned on without the ON:OFF key
operation, to display the weighing mode. Used when the balance is built into an automated system.
One hour warm up is necessary for accurate weighing.
10.4. Description Of The Item "Data Output Mode"
The parameter setting of "Data output mode (prt)" applies to the performance when the "Data
memory (data)" parameter is set to "2" (to store the weighing data) and when the data is
transmitted using the RS-232C interface.
Key mode
When the PRINT key is pressed with the stabilization indictor turned on, the balance outputs or
stores the weighing data and the display blinks one time.
Required setting dout prt 0 Key mode
Auto print modes A and B
When the displayed value is stable and the conditions of "Auto print polarity", "Auto print
difference" and reference value are met, the balance outputs or stores the weighing data.
When the PRINT key is pressed with the stabilization indictor turned on, the balance outputs or
stores the data and the display blinks one time.
Auto print mode A
Example For weighing each time a sample is placed and removed, with "ar-d" set
to "
1" (to adjust zero after the data is output).
Required setting dout prt 1 Auto print mode A (reference = zero)
dout ap-p Auto print polarity
dout ap-b Auto print difference
dout ar-d 1 Zero after output
Auto print mode B
Example For weighing while a sample is added.
Required setting dout prt 2 Auto print mode B (reference = last stable value)
dout ap-p Auto print polarity
dout ap-b Auto print difference
