54 BM series
12. Data Memory
Data memory is a function to store weighing data and calibration data in memory. The data stored in
memory are available for outputting at one time to a printer or personal computer.
Excluding date and time Up to 200 sets
Weighing data
Including date and time Up to 100 sets
Calibration report
Internal calibration
External calibration
Calibration test report
Internal test calibration
External test calibration
Last 50 sets
12.1. Notes On Using Data Memory
To use the memory function, set the "Data memory (data)" parameter
and "Time/Date output (5-td)" parameter of the function table. Refer to
"10. The Function Table" for details on setting the data memory.
For weighing data, the data contents to be stored and the storage
capacity depend on the "Time/Date output (5-td)" parameter setting.
If a different type of data exists in memory, "Clr" blinks in the upper left
of the display.
For example: You want to store weighing data but calibration data or
unit mass data remains in memory. "Clr" blinks.
If the stored data is incomplete or deleted, "err" blinks in the upper left
of the display.
Under such a condition, before storing data, delete the data in memory
as follows:
Releasing "Clr" or "err"
1 Press and hold the PRINT key until SClr "n"o with "no" blinking is displayed, then release the key.
2 Press the RE-ZERO key to display Clr "g"o with "go" blinking.
The type of data stored in memory appears in the upper left of the display as shown below:
Weighing data without time and date -d-
Weighing data with time and date d-t
Calibration report Hi5
3 Press the PRINT key to delete all the data in memory.
4 The balance displays end and returns to the weighing mode.
Upper lef
t
of
the display
