56 BM series
Caution
When weighing data is being stored in memory, the data can be output to a personal computer
using the RS-232C interface at the same time.
"fUl" indicates that memory is full or the memory capacity has been reached. More data can not
be stored unless the memory data is deleted.
Automatic self calibration can not be used while the interval memory mode is active.
The following commands can not be used during data storage.
Q Query command for weighing data.
S Query command for stable weighing data.
SI Query command for weighing data.
SIR Query command for continuous weighing data.
Setting the function table
Parameter settings for each output mode are as follows:
Item
Mode
Data output
mode
Auto print polarity,
difference
Data memory
function
Interval time
Key mode prt 0 Not used data 1
Auto print mode A prt 1 data 1
Auto print mode B prt 2
ap-a 0 to 2
ap-b 0 to 2
data 1
Not used
Interval mode prt 3 Not used data 1 int 0 to 8
Additional parameter settings, as follows:
No d-no off No 5-td 0 200 sets
Data number
Yes d-no on Time only 5-td 1
No 5-id off Date only 5-td 2
ID number
Yes 5-id on
Time and date
Both 5-td 3
100 sets
Enabling the data memory function
1 Press and hold the RANGE key until ba5fnc is displayed, then release the key.
2 Press the RANGE key several times to display dout .
3 Press the PRINT key.
4 Press the RANGE key three times to display data .
5 Press the RE-ZERO key to display data 1 .
6 Press the PRINT key to store the setting.
7 Press the CAL key to return to the weighing mode.
