BM series 7

Grounding terminal

Anti theft device

AC adaptor jack

USB interface

External key jack

Cap the terminal with accessory

rubber cap when it is not used.

Serial interface RS-232C

D-sub 9

ins

The DC Static eliminator

Electrode units of the

DC static eliminator

Separation plate

If unnecessary, remove it.

oint handle

When jointing the right (left) slide

door handle, the right (left) glass

door can be opened or closed

with the left (right) joint handle.

Bubble spirit level

Leveling foot

Glass door handle

The handle for the glass door.

The handle can be joined to the joint handle

Neutralization

area

Glass door handle

Display cover

LED of the static eliminator

Example of BM-20

Weighing

chamber

Display

Keys
