NOTE:



If your SMTP email server has authentication, enable it and enter the User name and

Password.



The SMTP email server name’s maximum number of characters is 64. Can include only

letters (uppercase and lowercase A~Z), numbers (0~9), hyphens (–), underlines (_) and

dots (.).



The sender’s email address’ maximum number of characters is 128.

3. Click Apply.

4. When the confirmation message appears, click OK to confirm.
