A
A-11 Print Options
Duplex
Duplex printing features are available only with plain paper media. If your copier has a
duplexing unit, you can print with the Top-Top and Top-Bottom duplex settings.
TO PRINT DUPLEX PAGES USING A DUPLEXING UNIT
1. Choose Print in your application, and locate the Duplex print option.
On Windows, duplex print options appear under the Finishing option bar in the
PostScript printer drivers.
On Mac OS, duplex print options appear in the print dialog box’s Printer Specific
Options pane.
2. Choose one of the Duplex settings:
Top-Top
—Prints the top of the image on Side 1 on the same edge of the page as the top
of the image on Side 2.
Top-Bottom —Prints the top of the image on Side 1 on the opposite edge of the page
from the top of the image on Side 2.
3. Print the job.
The following table shows how the Duplex settings correspond to printed output:
Top-Top Top-Bottom
Portrait
Landscape
1 2
1
2
1 2
1
2
