Konica Minolta CF9001 [28/126] Setting options and printing from windows nt 4

1-12 Printing from Windows Computers

TO SET PRINT OPTIONS USING THE PAGE SHORTCUTS

1. From the Fiery Printing tab, place your cursor over the page image and right-click.

2. Specify the appropriate settings for the print options.

3. Click OK.

Setting options and printing from Windows NT 4.0

You can print from Windows NT 4.0 using the Adobe PostScript printer driver

included on the User Software CD. In addition to using the User Software CD, you

can download printer drivers and printer ﬁles from the Fiery X3e with the Installer

WebTool (if the site administrator has enabled Internet access to the Fiery X3e).

For more information, see Getting Started.

Right-click the page image
