Konica Minolta CF9001 [25/126] The ﬁle name must include the sav extension and can be up to eight characters long not including the extension the ﬁle name does not have to match the settings name

1-9 Printing from applications

TO EXPORT SAVED SETTINGS

1. From the Fiery Printing tab, click Settings.

2. Select the Saved Settings you want to export, and click Export.

3. Browse to the location where you want to save the file, enter a file name, and click OK.

OTE: The ﬁle name must include the .sav extension and can be up to eight characters

long (not including the extension). The ﬁle name does not have to match the Settings

Name.

4. Click OK in the Settings dialog box.
