Konica Minolta CF9001 [37/126] For a list of fonts resident on the fiery x3e see appendix b

1-21 Printing with Fiery Downloader or WebDownloader

TO PRINT USING WEBDOWNLOADER

1. Create a PostScript, EPS, or PDF file. Specify the appropriate print options and include

(embed) any necessary fonts that are not resident on the Fiery X3e.

For a list of fonts resident on the Fiery X3e, see Appendix B.

2. Start Fiery WebTools and click WebDownloader.

For information on how to access WebDownloader, see “Fiery WebTools” on page 6-1.

3. Select the queue and the file you want to download.

4. Click Download.
