6
6-7 Tracking and Managing Print Jobs
Input Trays
An icon is used to represent the paper level in each tray. A red icon indicates the paper
tray is empty, a yellow icon indicates the paper tray is less than half full, and a green
icon indicates the paper tray is more than half full. Up and Down arrows allow you to
scroll through the available paper trays.
Toner
You can see how much toner your copier has by clicking the Toner tool. A warning
appears if the copier is getting low on toner.
My Fiery List
Click the Fiery check box in the main window to access the My Fiery List. You
can use the My Fiery List to specify the Fiery X3e servers you want to monitor using
Fiery Link. For information on setting up and changing the My Fiery List, see Getting
Started.
