Konica Minolta CF9001 [11/126] Appendix a print options

xi Contents

Appendix A: Print Options

Where to set print options

A-1

Print options and override hierarchy A-2

Default settings A-2

More information about print options A-9

Appendix B: Font List

PostScript printer fonts

B-1

Adobe Type 1 fonts B-1

Tr ueType fonts B-5

Appendix C: Troubleshooting

Maintaining optimal system performance

C-1

Troubleshooting

C-2

General printing problems C-2

Problems with print quality C-4

Problems with Fiery Downloader C-5

Problems with Fiery Scan C-7

Problems with Fiery WebTools C-7

Index
