Konica Minolta CF9001 [68/126] Enter the directory path using the touch panel keys

4-20 Special Features

TO PROGRAM DIRECTORY NAMES AND ADDRESSES OR E-MAIL

ADDRESSES WITH ONE TOUCH

1. Press Utility.

2. In the Touch Panel screen, touch Scanner Address Input.

3. Touch any of the unused keys.

4. Using the keys displayed on the screen, enter the destination name.

The destination name can be up to 10 characters.

5. Touch Next.

6. If you want to enter an e-mail address, verify that the E-mail button is selected, and

type in the e-mail address.

Enter the e-mail address using the touch panel keys.

If you want to enter a Folder, touch Folder and then touch Symbol.

Enter the directory path using the touch panel keys.

7. Touch Enter.

Illustration TBD

Unused keys

Next key
