1-13 Printing from applications

Once you have installed the Adobe PostScript printer driver and the PPD ﬁle, you can

specify print options.

With the Adobe PostScript printer driver, you can set options on a job-by-job basis (see

below), or establish default settings for all jobs printed from your computer to the

Fiery X3e (see page 1-16).

TO SET PRINT OPTIONS FOR A SPECIFIC WINDOWS NT 4.0 PRINT JOB

USING THE POSTSCRIPT PRINTER DRIVER

1. Choose Print in your application.

2. Make sure the Fiery X3e is selected as your printer and click Properties.

3. Click the Fiery Printing tab.
