Section 05 ENGINE MANAGEMENT (POWER TEK)
Subsection 02 (DIAGNOSTIC PROCEDURES)
A33C5KA
ensure that the protocol KW2000 is properly
selected in MPI under Choose protocol
A33C5LA
ensure the status bar shows the KW2000 and
the number 1 to the right. To communicate
with the ECM, number 1 must be displayed.
Number 1 indicates that the module is recognized
by the MPI.
F18H0WA
kW2000
CONNECTION SUCCESSFUL
If an X is shown, this means that no communi-
cation between the MPI and the ECM is possible.
In this case possible causes are:
ECM is not powered-up
wrong protocol is used
bad connection between MPI and module.
When connection is established, a beep pattern
will confirm the diagnostic mode is active.
NOTE: Leaving vehicle in diagnostic mode for a
long period will discharge battery. Be also aware
that some components will generate heat. Al-
ways disconnect VCK supply harness and supply
cable from vehicle/battery when not working on
vehicle.
NOTE: After disconnecting ECM connector for a
test and then reconnecting it, it will be neces-
sary to READ data from vehicle again to re-enable
B.U.D.S. communication. Otherwise, the follow-
ing message will occur.
A33C57A
mmr2005-106 211
