DIP-20 - Operating the DIP-20 Remotely Using the Web Pages

There are six Web pages described in the following sections:

 Switching (see Section 9.2)

 Device Settings (see Section 9.3)

 Video and Audio Settings (see Section 9.4)

 Authentication (see Section 9.5)

 EDID (see Section 9.6)

 About Us (see Section 9.7)

9.1.1 The Upload/Save Configuration Facility

The Upload/Save Configuration facility (see item 4 in Figure 9) lets you retrieve

and save a configuration.

To upload a configuration:

1. Click the Upload button.

The File Upload browser window appears.

2. Browse to the required file and press Open.

The configuration is retrieved and the success message is displayed.

To save the current configuration:

1. Click the Save button.

The Save Configuration success message is displayed.

2. Do either of the following:

 Click Download to either open the file or save it to the required

location

—OR—

 Click OK to complete the procedure
