DIP-20 - Technical Specifications
33
DIMENSIONS:
18.75cm x 11.5cm x 2.54cm (7.38” x 4.53” x 1.0”) W, D, H
WEIGHT:
0.46kg (1.01lbs) approx.
SHIPPING WEIGHT:
1.16kg (2.56lbs) approx.
ENVIRONMENTAL
REGULATORY
COMPLIANCE:
Complies with appropriate requirements of RoHs and
WEEE
INCLUDED
ACCESSORIES:
Power adapter 48V DC 1.36A
ADC-DPM/HF DisplayPort (M) to HDMI (F) adapter cable
Power cord
OPTIONS:
Rack adapter RK-T2B
WARRANTY:
7 years parts and labor
10.1 Default IP Parameters
Parameter
Values
Default
Device
Name
Any alphanumeric string up to 14
chars (can include hyphen, but
not at the beginning or end)
KRAMER_
DHCP
ON/OFF
OFF
IP Address
Any valid IP address
192.168.1.39
Mask
Any valid network mask
255.255.0.0
Gateway
Any valid gateway address
192.168.0.1
TCP Port
0 to 65535
5000
UDP Port
0 to 65535
50000
10.2 Default Logon Credentials
Parameter
Values
Name
Admin
Password
Admin
10.3 Supported Resolutions
10.3.1 HDMI
Resolution
Refresh Rate (Hz)
640x480p
85Hz; 75Hz; 72Hz; 60Hz; 59.95Hz
720x480p
60Hz
720x480i
30Hz
720x576p
50Hz
800x600p
85Hz; 75Hz; 72Hz; 60Hz
848x480p
60Hz
852x480p
60Hz
