26
DIP-20 - Operating the DIP-20 Remotely Using the Web Pages
#
Item
Description
9
Firmware
upgrade
Section
BROWSE
button
Click to open a window to browse to the new firmware file
10
START
UPGRADE
button
Click to start the upgrade process following the selection of
the new firmware file
11
Factory Reset Button
Click to reset the device to factory default parameters. After
the success message is displayed, power cycle the device
12
Set Button
Click to store a changed parameter.
Note: If you do not click the Set button, the new parameter is
not stored
To upgrade the firmware:
1. Click the Browse button.
The Windows Browser opens.
2. Browse to the required file.
3. Select the required file and click Open.
The firmware file name is displayed in the Firmware Upgrade page.
4. Click Start Upgrade.
The firmware file is loaded and a progress bar is displayed.
Do not interrupt the process or the DIP-20 may be damaged.
5. When the process is complete reboot the device.
The firmware is upgraded.
To reset the DIP-20 to factory default parameters:
1. Click the Factory reset button.
The confirmation message is displayed.
2. Click OK to continue or Cancel to exit the procedure.
3. Click OK.
The progress message is displayed.
On completion, the success message is displayed.
4. Click OK.
