30
DIP-20 - Operating the DIP-20 Remotely Using the Web Pages
#
Item
Description
3
Input 1 button
Click to read the EDID from input 1 (HDMI 1)
4
Input 2 button
Click to read the EDID from input 2 (HDMI 2)
5
Input 3 button
Click to read the EDID from input 3 (VGA)
6
BROWSE
button
Click to open the file browser to select an EDID
file on your computer
7
Short Summary Information
Section
Displays the current election of EDID source,
destination, video resolution, audio availability,
and status
8
Copy to
Section
Inputs selection
box
Check to select both inputs
9
Lock button
Locks the EDID on the currently selected input
10
Input 1 button
Click to select input 1 as the destination (HDMI 1)
11
Input 2 button
Click to select input 2 as the destination (HDMI 2)
12
Input 3 button
Click to select input 3 as the destination (VGA)
13
COPY Button
Click to copy the EDID from the selected source
to the selected destination
14
REFRESH Button
Click to refresh the display
To copy EDID data from a source to one or both inputs:
1. Click the source button from which to read the EDID (default, output,
input, or EDID file).
The button changes color and the EDID summary information reflects the
selection and EDID data.
2. Click a destination input, or select both inputs by checking the Inputs
check-box.
All selected input buttons change color and the EDID summary
information reflects the selection and EDID data.
3. Click the Copy button.
The “EDID was copied” success message is displayed and the EDID data
is copied to the selected input(s).
4. Click OK.
9.7 The About Us Page
The DIP-20 About Us page displays the Web page version and Kramer
Electronics Ltd company details.
