SIERRA VIDEO

Installation

Rack Mounting

Carefully inspect the panel to ensure that there has been no shipping damage. Make

sure all shipping material is removed from the RCP frame.

The control panel described in this manual can be rack mounted in a standard 19" (RU)

EIA rack assembly and includes rack "ears" at the ends of the front of the panel. It does

not require spacing above or below the unit for ventilation.

To rack mount any of the RCP panels, simply place the unit's rack ears against the rack

rails of the rack, and insert proper rack screws through each of the holes in the rack ears.

Always rack mount the panel prior to plugging the unit into a power receptacle or

attaching any cables.

CAUTION!

The operating temperature range of this product is 0 to 45ºC. Do not exceed the maximum (45ºC)

or minimum (0ºC) operating temperature.

If installed in a closed or multi-rack assembly, the operating ambient temperature of the rack

environment may be greater than the room ambient temperature. Therefore, consideration should

be given to installing the equipment in an environment compatible with the manufacturer’s

maximum rated ambient temperature.

Dimensions

Aspen RCP-7272 is 2 rack units high, 19” wide, and 1.25” deep.
