Troubleshooting

Introduction

Button Lamp Test

If Button 1 is held down when power is first applied, the control panel will enter a

Keyboard/Lamp test function. If no button is held down, the control panel will go directly

to the status mode.

1) On power up, press and hold button 1 until all GREEN LEDs turn on

2) For button 1, pressing the button will go through the following sequence

a. All BLUE LEDS on

b. All RED LEDS on

c. All LEDs off

d. Button 1 GREEN LED on

e. Button 1 BLUE LED on

f. Button 1 RED LED on

g. Button 1 off

h. All GREEN LEDs on

i. Go back to step a.

3) For all other buttons, each press of the button will cycle through each LED supported

by that button and off. If you continue to push the button, it will then repeat the

sequence. For example, if button 2 is off, pressing it will go through the following

sequence.

a. GREEN

b. BLUE

c. RED

d. off

e. Go back to step a.

4) To exit test mode, remove and re-apply power to the unit.
