ASPEN 7272 RCP CONTROL PANEL

Setup Functions

Return to Factory Default

To reset the RCP to Factory Default conditions requires simultaneous button pushes to

execute the command to reset.

 Press and hold the FUNC button until it turns BLUE, while holding the FUNC

button.

 Press and hold Buttons 1 and 2.

 Buttons 1 and 2 will be BLUE. NOTE: these buttons do not light until both

are held. If either button is released, both will turn off.

 The TAKE button blinks RED.

 While continuing to hold the FUNC button and Buttons 1 and 2, press the TAKE

button to execute. The RCP will be reset to Factory defaults.

CAUTION!

All of your configuration changes in the RCP will be lost when you return to factory default.

If you hold down button 1 too long after hitting the TAKE button, the front panel may go into

“Button Lamp Test” mode. All green LEDs will be on when this happens. To exit this mode, power

cycle the RCP by removing and re-applying the power.

Note:

Releasing the FUNC button will exit the Setup mode and return the panel to its previous state.

IP Address

The IP address may be viewed or changed from the front panel.

To display the IP address;

 Press and hold the FUNC button until it turns BLUE. Release the FUNC button to exit.

 Press Button 72. This button will turn blue.

• Buttons 11 through 14 will turn GREEN if the IP Address can be changed from

the front panel. Otherwise, these buttons will be BLUE.

 Press Button 11. This button will now blink.

• Three of the Buttons 1 - 10 (for 0) will turn on briefly to display the 1st octet of the

IP address.

 Press Button 12. This button will now blink.

• Three of the buttons 1 - 10 (for 0) will turn on briefly to display the 2nd octet of

the IP address.

 Press Button 13. This button will now blink.

• Three of the buttons 1 - 10 (for 0) will turn on briefly to display the 3rd octet of the

IP address.

 Press Button 14. This button will now blink.

• Three of the buttons 1 - 10 (for 0) will turn on briefly to display the 4th octet of the

IP address.

 Release the FUNC button to exit.
