Foxconn at-9700 black [15/53] Placement and connecting
![Foxconn at-9330 black [15/53] Placement and connecting](/views2/1167522/page15/bgf.png)
9
PLACEMENT AND CONNECTING
4. Install the other side of the VESA mount.
To fasten the VESA mount, your display must comply with VESA75 or VESA100
standard.
