BIOS SETUP

SATA Conguration

► SATA Controller(s)

This item is used to enable or disable SATA controller.

► SATA Mode Selection

This item is used to set the operating mode of your SATA ports.

[AHCI] - The Advanced Host Controller Interface (AHCI) specication describes the register level

interface for a Host Controller for Serial ATA. The specication includes a description of the hardware/

software interface between system software and the host controller hardware. AHCI provides more

advanced features including SATA features, but some SATA drives may not support AHCI, unless they

are labeled with AHCI support in its specication. If your motherboard supporting AHCI, and you have

a SATA device, which also supports AHCI, then you can select IDE option to have fair performance

(only PATA, SATA level), or you can select AHCI to get its best performance.

[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.

Main Advanced Boot Power Health Security Save&ExitF-center

→ ←: Select Screen

↑ ↓/Click: Select Item

Enter/Dbl Click: Select

+/-: Change Opt.

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit

Version 2.17.1246. Copyright (C) 0001 American Megatrends, Inc.

SATA Controller(s) [Enabled]

SATA Mode Selection [AHCI]

Serial ATA Port1 Empty

Serial ATA Port2 Empty

Enabled or Disabled

SATA Device.
