25
BIOS SETUP
Onboard Device Conguration
► Onboard LAN Controller
This item is used to enable or disable the onboard LAN controller
► USB Support
This item is used to enable or disable USB Controller Support.
► Legacy USB Support
This item is used to enable the support for USB devices on legacy OS. If you have a USB keyboard or
mouse, set to enabled.
[Enabled]: This option will enable the legacy USB support.
[Disabled]: This option will keep USB devices available only for EFI applications.
► Azalia
This item is used to enable or disable the Azalia HD Audio Controller.
Main Advanced Boot Power Health Security Save&ExitF-center
→ ←: Select Screen
↑ ↓/Click: Select Item
Enter/Dbl Click: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Version 2.17.1246. Copyright (C) 0001 American Megatrends, Inc.
Onboard Device Configuration
Onboard LAN Controller [Enabled]
USB Support [Enabled]
Legacy USB Support [Enabled]
Azalia [Enabled]
Enabled/Disabled
On-
board LAN Control-
ler.
