Foxconn at-9700 black [4/53] Package contents
![Foxconn at-9330 black [4/53] Package contents](/views2/1167522/page4/bg4.png)
Package Contents
We DO NOT guarantee it is in compliance with the Safety Certicates if you add on an
extension cable to NanoPC USB Flash Disk in the package.
NanoPC Seat Base VESA Mount
Power Adapter Power Cord Easy Guide
USB Flash Disk Screws
Mini PCIe Half Card Support
Bracket
U-Disk
Содержание
- Safety notice 3
- Package contents 4
- We do not guarantee it is in compliance with the safety certificates if you add on an extension cable to nanopc usb flash disk in the package 4
- Bios setup 5
