BIOS SETUP
North Bridge
► Total Memory
This item displays the current using memory information.
► DIMM#0/#1
These items display the memory size installed on each slot.
► Integrated Graphics
This item allows you to determine whether to allocate memory for the integrated graphics controller
from the system memory. Options: [Auto], [Manual].
[Auto]-Auto the integrated graphics controller.
[Manual]- Manual the integrated graphics controller.
► DVMT Pre-Allocated
This item is used to select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the
Internal Graphics Devices.
► DVMT Total Gfx Memory
This item is used to select DVMT 5.0 Total Graphic memory size used by internal graphics device.
Main Advanced Boot Power Health Security Save&ExitF-center
→ ←: Select Screen
↑ ↓/Click: Select Item
Enter/Dbl Click: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Version 2.17.1246. Copyright (C) 0001 American Megatrends, Inc.
North Bridge Configuration
Memory Information
Total Memory 4096 MB (DDR3/DDR3L 1600)
DIMM#0 4096 MB (DDR3/DDR3L)
DIMM#1 Not Present
Memory Configuration
Internal Graphics [Auto]
DVMT Pre-Allocated [64M]
DVMT Total Gfx Memory [256M]
Keep IGO enabled based
on the setup options.
