BIOS SETUP

In order to reduce power to a minimum, it is assumed that the hardware platform has powered off all

devices. Platform context is maintained. (also called Suspend to Disk)

S5 - The S5 state is similar to the S4 state except that the OS does not save any context. The system

is in the “soft” off state and requires a complete boot when it wakes. Software uses a different state

value to distinguish between the S5 state and the S4 state to allow for initial boot operations within the

BIOS to distinguish whether or not the boot is going to wake from a saved memory image.

► ACPI Sleep State

This item is used to set the energy saving mode of the ACPI function. When you select “S1 (POS)”

mode, the power is always on and computer can be resumed at any time. When you select “S3

(STR)” mode, the power will be down after a period of time. The status of the computer before it

entering STR will be saved in memory, and the computer can quickly return to previous state when

the STR function wakes.

► Resume By USB Device(s)

This item is used to enable or disable the USB device(s) to generate a wake up.

► Resume By Onboard LAN

This item is used to enable or disable the onboard LAN to generate a wake up.

► Resume By RTC

This item is used to enable or disable RTC alarm event to generate a wake up.

RTC is system real time clock.

► RTC Alarm Date(Days)

When Resume by RTC is enabled, select a specic date to generate a wake up.

► RTC Alarm Time(HH:MM:SS)

When Resume by RTC is enabled, select a specic time to generate a wake up.

► Energy-using product

This item is used to congure the DeepSx Mode conguration.

► Restore AC Power Loss

This item is used to set which state the PC will take with when it resumes after an AC power loss.
