20
BIOS SETUP
CPU Conguration
► Limit CPUID Maximum
This item is used to enable or disable CPUID maximum value limit conguration.
► Execute Disable Bit
This item is used to enable/disable the Execute Disable Bit feature.
Intel’s Execute Disable Bit functionality can help prevent certain classes of malicious buffer overow
attacks when combined with a supporting operating system .
► Intel Virtualization Technology (Appears only when CPU supports)
Virtualization (i.e. Intel® Vanderpool Technology) allows a platform to run multiple operating systems
and applications in independent partitions or “containers.” One physical compute system can function
as multiple “virtual” systems. Vanderpool Technology can help improve future virtualization solutions.
This item will be displayed only when the CPU is supporting this feature and the setting is used to
enable/disable it.
► EIST
Main Advanced Boot Power Health Security Save&ExitF-center
→ ←: Select Screen
↑ ↓/Click: Select Item
Enter/Dbl Click: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Version 2.17.1246. Copyright (C) 0001 American Megatrends, Inc.
CPU Configuration
CPU Brand Name:
Intel(R) Pentium(R) 3805U @ 1.90GHz
CPU Signature 306d4
Microcode Patch 11
Max CPU Speed 1900 MHZ
Min CPU Speed 500 MHz
CPU Speed 1900 MHz
Processor Cores 2
Intel HT Technology Not Supported
Intel VT-x Technology Supported
Intel SMX Technology Not Supported
64-bit Supported
EIST Technology Supported
CPU C3 state Supported
CPU C6 state Supported
CPU C7 state Supported
L1 Data Cache 32 KB X 2
L1 Code Cache 32 KB X 2
L2 Cache 256 KB X 2
L3 Cache 2 MB
L4 Cache Not Present
Limit CPUID Maximum [Disabled]
Execute Disabled Bit [Enabled]
Intel Virtualization Technology [Enabled]
EIST [Enabled]
Turbo [Enabled]
CPU C3 Report [Enabled]
CPU C6 Report [Enabled]
Disabled for Windows XP
