BIOS SETUP
► Smart Boot Menu
When PC starts, it will ask you to press [Del] key to enter setup or press [F7] key to enter smart boot
menu. If [Disabled] is selected, then pressing [F7] has no function. This also prevents user without
password trying to get into your computer through smart boot menu.
