Chapter 1 Getting to Know Your MSC

Management Switch Card User’s Guide

• The VLC1324G-51 for VDSL2 over POTS (Annex A) Line Card may be referred to as the

“VLC1324G”, the “VLC” or the “line card” in this User’s Guide.

• The VLC1324G-53 for VDSL2 over ISDN (Annex B) Line Card may be referred to as the

“VLC1324G”, the “VLC” or the “line card” in this User’s Guide.

• The VLC1348G-51 for VDSL2 over POTS (Annex A) Line Card may be referred to as the

“VLC1348G”, the “VLC” or the “line card” in this User’s Guide.

• The VLC1348G-53 for VDSL2 over ISDN (Annex B) Line Card may be referred to as the

“VLC1348G”, the “VLC” or the “line card” in this User’s Guide.

• The VLC1424G-56 for VDSL2 over POTS (Annex A) Line Card may be referred to as the

“VLC1424G”, the “VLC” or the “line card” in this User’s Guide.

• The ELC1220G-55 Fiber-based Fast Ethernet Line Card may be referred to as the “ELC1220G”,

the “ELC” or the “line card” in this User’s Guide.

• The VOP1248G VoIP Line Card may be referred to as the “VOP1248G”, the “VOP” or the “line

card” in this User’s Guide.

• The VOP1372G VoIP Line Card may be referred to as the “VOP1372G”, the “VOP” or the “line

card” in this User’s Guide.

• The IMA1408G for Inverse Multiplexing over ATM Line Card may be referred to as the

“IMA1408G”, the “IMA” or the “line card” in this User’s Guide.

• The GLC1320G-55 for Gigabit Ethernet Line Card may be referred to as the “GLC1320G”, the

“GLC” or the “line card” in this User’s Guide.

1.1.1 Applications

• The IES can provide Internet access and multimedia services for Multiple Tenant Units (MTU).The

following diagram depicts a typical application of the IES-5000 with DSL modems, in a large

residential building, that leverages existing phone line wiring to provide Internet access to all

tenants. ADSL service can coexist with voice service on the same line.

Figure 1 MTU Application
