- To deactivatethekeyfunction, switch the hob off (if it
is on) by selecting the “ON/OFF” key.
- Once it is off, switch the hob back on.
- Press the “-” key and the R2 (Fig.2), R4 (Fig.3) or R3 (Fig.4)
key simultaneously according to the model you own.
- Press the“-” key a second time.
- Zeros will appear on all the displays for a few seconds.
- If the cooker top is switched off with the KEY function active,
when subsequently activated the top will be in the same
situation, meaning with the KEY function active.
- If the hob is switched on and theLockfunction is enabled,
button ON/OFF will still work.
•Magneticsensor:
- The hob is equipped with a pan sensor; when the pan is
removed or badly positioned, the
symbol will appear.
If, on the other hand, the surface of the glass is still hot, the
symbol will appear alternating with the .
•O.S.D.(OverowSafetyDevice):
The hob is equipped with a safety system which moves all
hotplates to the OFF position and activates the safety lock
when liquids or items are detected on the control panel.
These symbols will ash on the display:
.
They can be deactivated by removing the item or the liquid.
The hob will switch o automatically.
•Timer:
Note: the Timer can be activated on all the cooking zones
simultaneously.
This function allows to establish the time (from 1 to 99 minutes)
or automatic switch-o of the cooking zone selected.
Activation:
1- Select the cooking zone “C”.
2- Set the cookinglevel.
3- Press the “+” and “-” keys simultaneously. The decimal
point “•” will start to ash. The time on the timer will appear
on the relative displays.
4- Adjust the time within about 10 seconds by using the
“+” and “-” keys. By pressing the “-” key directly the time
will be set at 30 minutes.
3/4burnerversion:
- If the decimal point “•” appears on the displays, it means
that timer is active.
- During cooking the time set previously with the timer is
not displayed.
- In order to view the time remaining on the Timer of a
cooking zone, select that cooking zone and then press
the “+” and “-” keys simultaneously. On the “B1” and
“B2” displays (4 burner version) and on the “M2” and
“N” displays (3 burner version) the remaining time will
appear.
- When time is up an acoustic signal beeps and the timer
displays ash. Any key can be selected to stop the acoustic
signal. If you leave the acoustic signal it will deactivate
after about 2 minutes.
2burnerversion:
- If the decimal point “•” appears on the displays, it means
that timer is active.
- When the decimal point ashes it indicates the zone with
the least time on the timer and therefore the rst zone will
switch o. The timer display will show the remaining time
of the next zone which will switch o.
- In order to view the time remaining on the Timer of a
cooking zone, select that cooking zone and then press the
“+” and “-” keys simultaneously. Afterwards the remaining
time will appear on the timer “F” display.
- When time is up an acoustic signal beeps and the timer
displays ash. Any key can be selected to stop the acoustic
signal. If you leave the acoustic signal it will deactivate
after about 2 minutes.
To deactivatethetimerfunctionbeforethesettime,
select the cooking zone and then press the “+” and “-” keys
simultaneously. By selecting the “-” key a second time the
time goes to 0. After that the cooking zone will continue its
standard function.
•MinuteMinder(Countdown):
This function can be used both with cooking zones activated/
deactivated and with the timer inserted.
- The Minute Minder allows to set an established countdown
that goes from 1 to 99 minutes.
On expiry of the time, the hob emits an acoustic signal without
changing the active functions.
Activation:
1- The function is activated with the hob on.
2- Press the “+” and “-” keys simultaneously.
3- Adjust the time within about 10 seconds by using the
“+” and “-” keys. By pressing the “-” key directly the time
will be set at 30 minutes.
3/4burnerversion:
- If no zone is activated or if the hob is deactivated by
selecting the ON/OFF key, the decimal point on the R2
and R3 displays begins to flash.
- If the hob is turned on with the Minute Minder function
active, zeros will appear on all the displays. By pressing
the “+” and “-” keys simultaneously, the remaining time
will appear.
- In order to view the remaining time of the Minute
Minder press the“+” and “-” keys simultaneously. On the
“B1” and “B2” displays (4 burner version) and on the “M2”
and “N” displays (3 burner version) the remaining time will
appear.
- When time is up an acoustic signal beeps and the timer
displays ash. Any key can be selected to stop the acoustic
signal. If you leave the acoustic signal it will deactivate
after about 2 minutes.
2burnerversion:
- If the “F” displays of the timer or the hob are deactivated,
by selecting the ON/OFF key the remaining time of the
Minute Minder will appear
- If the Minute Minder and the Timer are active, the “F”
display will signal the time left. If it is the Timer function,
the decimal point of the concerned zone will flash.
- When time is up an acoustic signal beeps and the timer
displays ash. Any key can be selected to stop the acoustic
signal. If you leave the acoustic signal it will deactivate
after about 2 minutes.
To deactivatetheMinuteMinderfunctionbeforetheset
time, press the “+” and “-” keys simultaneously. By selecting
the “-” key a second time the time goes to zero. After that the
cooking zone will continue its standard function.
It is possible to use the Minute Minder and the Timer
simultaneously.
•Booster(Fig.2-3-4):
Depending on the appliance model, it may be tted with a
Booster system which can be used to speed up cooking times
through the application of a power level which is greater than
the nominal value, within a dened period of time.
The cooking zones supplied with this function are indicated
- 31 -
