B-1
Appendix B: System Specifi cations
Appendix B
System Specifi cations
Processors
Dual Intel
®
Xeon
®
E5-2600 Series processors in LGA 2011 sockets
Note: Please refer to our web site for a complete listing of supported processors.
Chipset
Intel C600
Memory Capacity
Eight DIMM sockets that can support up to 256 GB of registered DDR3-
1600/1333/1066/800 RDIMM memory
See the memory section in Chapter 5 for details.
SATA Controller
Intel on-chip controller for six SATA ports, RAID 0, 1 5 and 10 supported
SATA Drive Bays
Four hot-swap drive bays to house four SATA hard drives
Expansion Slots
Riser card for one PCI-E 2.0 x16 add-on card
Serverboard
X9DRD-iF
Dimensions: 13 x 10.3 in (330 x 262 mm)
Chassis
SC813TS-441CBP (1U rackmount)
Dimensions: (WxHxD) 17.2 x 1.7 x 25.6 in. (437 x 43 x 650 mm)
Weight
Barebone Weight: 22 lbs. (10 kg.)
