Chapter 5: Advanced Serverboard Setup
5-19
DOM PWR Connector
A Disk On Module (DOM) Power Con-
nector is located at JDS1. This connec-
tor is used to provide power to auxilliary
fl ash memory media attached to a SATA
port. See the table on the right for pin
defi nitions.
DOM PWR Connector
Pin Defi nitions
Pin Defi nition
15V
2 Ground
3 Ground
Serial_Link-SGPIO
Pin Defi nitions
Pin# Defi nition Pin Defi nition
1NC 2 NC
3 Ground 4 DATA Out
5 Load 6 Ground
7 Clock 8 NC
T-SGPIO 0/1 Headers
Two T-SGPIO (Serial-Link General
Purpose Input/Output) headers are
located near the SATA connectors on
the serverboard. These headers are
used to communicate with the enclosure
management chip in the system. See
the table on the right for pin defi nitions.
Refer to the board layout below for the
locations of the headers.
NC = No connection
Standby Power Header
The +5V Standby Power header is lo-
cated at JSTBY1 on the serverboard.
See the table on the right for pin defi ni-
tions. (You must also have a card with
a Standby Power connector and a cable
to use this feature.)
Standby PWR
Pin Defi nitions
Pin# Defi nition
1 +5V Standby
2 Ground
3 Wake-up
