5-18
SUPERSERVER 6017R-TDF User's Manual
TPM/Port 80 Header
Pin Defi nitions
Pin # Defi nition Pin # Defi nition
1 LCLK 2 GND
3 LFRAME# 4 <(KEY)>
5 LRESET# 6 +5V (X)
7 LAD 3 8 LAD 2
9 +3.3V 10 LAD1
11 LAD0 12 GND
13 SMB_CLK4 14 SMB_DAT4
15 +3V_DUAL 16 SERIRQ
17 GND 18 CLKRUN# (X)
19 LPCPD# 20 LDRQ# (X)
Overheat LED/Fan Fail
The JOH1 header is used to connect
an LED indicator to provide warnings
of chassis overheating and fan failure.
This LED will blink when a fan failure
occurs. Refer to the tables on right for
pin defi nitions.
Overheat LED
Pin Defi nitions
Pin# Defi nition
1 5vDC
2 OH Active
OH/Fan Fail LED
Status
State Message
Solid Overheat
Blinking Fan Fail
Trusted Platform Module Header
The JTPM1 header is used to connect a
Trusted Platform Module (TPM), available
separately from a third-party vendor. A
TPM is a security device that allows en-
cryption and authentication of hard drives,
disallowing access if the TPM associated
with it is not installed in the system. See
the table on the right for pin defi nitions.
Power SMB (I
2
C) Connector
The Power System Management Bus
(I
2
C) connector (JPI
2
C1) monitors power
supply, fan and system temperatures.
See the table on the right for pin defi ni-
tions.
PWR SMB
Pin Defi nitions
Pin# Defi nition
1 Clock
2 Data
3 PWR Fail
4 Ground
5 +3.3V
IPMB
A System Management Bus header for
IPMI 2.0 is located at JIPMB1. Connect
the appropriate cable here to use the
IPMB I
2
C connection on your system.
IPMB Header
Pin Defi nitions
Pin# Defi nition
1 Data
2 Ground
3 Clock
4 No Connection
