Supermicro sys-6017r-tdf [55/106] 11 sata drive ports

Chapter 5: Advanced Serverboard Setup

5-23

5-11 SATA Drive Ports

SATA Port Pin Deﬁ nitions

(SATA0 ~ SATA5)

Pin # Deﬁ nition

1 Ground

2 TXP

3 TXN

4 Ground

5 RXN

6 RXP

7 Ground

SATA Ports/SCU Connectors

There are four SATA 2.0 (SATA2~SATA5)

and two SATA 3.0 (SATA0-1) ports

located on the X9DRD-iF. In addition,

four SCU connectors (SCU0~3) are also

provided on the board. See the table on

the right for pin deﬁ nitions.
