Chapter 5: Advanced Serverboard Setup
5-13
5-8 Connector Defi nitions
Power Connectors
A 24-pin main power supply connector
(JPW1), two 8-pin CPU power con-
nectors (JPW2/3) and one 4-pin power
connectors (JPW5) are located on the
serverboard. These power connectors
meet the SSI EPS 12V specification
and must be connected to your power
supply to provide adequate power to the
system. See the table on the right for pin
defi nitions.
8-pin Power Pin
Defi nitions (JPW2, JPW3)
Pins Defi nition
1 through 4 Ground
5 through 8 +12V
8-Pin Power Connectors
In addition to the ATX main power, two
8-pin 12V power connector located at
JPW2 and JPW3 are also required con-
nections. See the table on the right for
pin defi nitions.
ATX Power 24-pin Connector
Pin Defi nitions (JPW1)
Pin# Defi nition Pin # Defi nition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 COM 3 COM
16 PS_ON 4 +5V
17 COM 5 COM
18 COM 6 +5V
19 COM 7 COM
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 COM 12 +3.3V
Power LED
The Power LED connection is located on
pins 15 and 16 of JF1. Refer to the table
on the right for pin defi nitions.
NMI Button
The non-maskable interrupt button head-
er is located on pins 19 and 20 of JF1.
Refer to the table on the right for pin
defi nitions.
NMI Button
Pin Defi nitions (JF1)
Pin# Defi nition
19 Control
20 Ground
Power LED
Pin Defi nitions (JF1)
Pin# Defi nition
15 3.3V
16 PWR LED
HDD LED
The HDD LED connection is located on
pins 13 and 14 of JF1. Attach a cable here
to indicate HDD activity. See the table on
the right for pin defi nitions.
HDD LED
Pin Defi nitions (JF1)
Pin# Defi nition
13 3.3V Standby
14 HD Active
