Chapter 1
Introduction
1-1 Overview
The SuperServer 6017R-TDF is a high-end server comprised of two main subsys-
tems: the SC813TS-441CBP 1U chassis and the X9DRD-iF serverboard. Please
refer to our web site for information on operating systems that have been certifi ed
for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the 6017R-TDF, as listed below:
• Two 10-cm blower fans (FAN-0135L4)
• Two passive CPU heatsinks (SNK-P0047PS)
• One RSC-RR1U-E16 riser card
• SATA Accessories
One SATA backplane (BPN-SAS-815T)
Four 3.5" hard drive carriers (MCP-220-00075-0B)
• One rackmount kit (MCP-290-00102-0N)
• One CD containing drivers and utilities
• SuperServer 6017R-TDF User's Manual
Chapter 1: Introduction
1-1
