Chapter 5: Advanced Serverboard Setup
5-9
Processors and their Corresponding Memory Modules
CPU# Corresponding DIMM Modules
CPU1 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 P1-DIMMD1
CPU2 P2-DIMME1 P2-DIMMF1 P2-DIMMG1 P2-DIMMH1
Processor and Memory Module Population
Number of
CPUs+DIMMs
CPU and Memory Population Confi guration Table
(For optmnal performance, install DIMMs in pairs)
1 CPU &
2 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1
1 CPU &
4 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1
2 CPUs &
2 DIMMs
CPU1 + CPU2
P1-DIMMA1, P2-DIMME1
2 CPUs &
4 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1
2 CPUs &
6 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1, P2-DIMME1/P2-DIMMF1/P2-DIMMG1
2 CPUs &
8 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-
DIMMG1/P2-DIMMH1
RDIMM Support POR on the E5-2600 Series Processor Platform
DIMM
Slots per
Channel
DIMMs
Popu-
lated
per DDR
Channel
RDIMM/LRDIMM
Type
(RDIMM: Reg.=
Registered,
LRDIMM=Load
Reduced)
POR Speeds (in MHz) Ranks per DIMM
(Any Combination)
1 1 Reg. ECC DDR3 800/1066/1333/1600 SR, DR, or QR
Population Rules:
1. Any combination of x4 and x8 RDIMMs with 1 Gb or 2 Gb DRAM Density are supported.
2. Populate DIMMs starting with DIMM# A1.
3. When mixing QR with SR or DR, put the QR in DIMM#A1 fi rst.
