1-3
Chapter 1: Introduction
1-3 Server Chassis Features
The following is a general outline of the main features of the SC813TS-441CBP
chassis.
System Power
The SC813TS-441CBP chassis includes a single 440-480W power supply. Power
must be removed from the system when removing the power supply. See Chapter
6 for details.
SATA Subsystem
For the 6017R-TDF, the SC813TS-441CBP chassis was designed to support four
SATA hard drives, which are hot-swappable units.
Control Panel
The SC813TS-441CBP's control panel provides important system monitoring and
control information. LEDs indicate power on, network activity, hard disk drive activ-
ity and system overheat conditions. The control panel also includes a main power
button and a system reset button.
Cooling System
The SC813TS-441CBP chassis has an innovative cooling design that features two
10-cm high-performance blower fans. Each of these fans plug into a chassis fan
header on the serverboard.
A fan speed control setting in BIOS allows fan speed to be determined by system
temperature [the recommended setting is Standard (Server)].
