5-12
SUPERSERVER 6017R-TDF User's Manual
Jumper Description Default Setting
JBT1 Clear CMOS See Section 5-9
JI
2
C1/JI
2
C2 SMB to PCI-E Slots Off (Disabled)
JPB1 BMC Enable/Disable Pins 1-2 (Enabled)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled)
JWD1 Watch Dog Timer Enable/Disable Pins 1-2 (Reset)
Connectors Description
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
FAN1~8 CPU/System Fan Headers
I-SATA 0~5 SATA 3.0 (I-SATA0/1) and SATA 2.0 (I-SATA2~5) Ports
JBAT1 Onboard Battery (See Chpt. 3 for Used Battery Disposal)
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JOH1 Overheat LED Indicator
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPW1 24-Pin ATX Main Power Connector
JPW2/3 12V 8-Pin Power Connectors
JPW5 12V 4-Pin Power Connectors
JSD1 SATA DOM (Device on Module) Power Connector
JSTBY1 +5V Standby Power Header
JTPM1 TPM (Trusted Platform Module)/Port 80
JUIDB UID (Unit Identifi cation) Switch
LAN1/LAN2 G-bit Ethernet Ports 1/2
IPMI LAN IPMI Dedicated LAN
SP1 Onboard Buzzer (Internal Speaker)
SCU0~3 SCU SATA 2.0 Ports
(3-)SGPIO 1 Serial Link General Purpose I/O Header (for SCU)
(T-)SGPIO 1/2 Serial Link General Purpose I/O Header (for SATA)
USB 0/1, 2/3 USB 0/1, 2/3 Ports
USB 4/5, USB 8/9 Front Panel Accessible USB Headers (4/5, 8/9)
USB 6 Type A USB Embedded Drive Connector
